Portable Outdoor Power Station: HD-AMB108, 3*6mm²+0.75mm², 7.4KW,
NEMA 14-50P
Product Description
1. Portable household portable charger
2. After charging and use, it can be carried with the vehicle
3. The power of the device is as low as 3W in the on-machine state,
saving energy and low consumption
4. Three color charging indicator light, indicating charging
related values
5. Numerical screen display, displaying real-time charging data of
the charging gun
Describe
The HD-AMB108 charging gun is a portable charging product that
meets the American AC power standards, with a rated maximum AC
output power of 7.4KW and a weight of approximately 3.4KG. It is
suitable for household new energy on-board chargers, outdoor
travel, emergency relief, and outdoor work.
General specifications
| Detailed parameters | Parameter Details |
| Name and model | HD-AMB108 |
Appearance structure | plug model | NEMA 14-50P |
| product type | Plug and Charge |
| Shell material | Gun Head - Control Box PC9330 |
Equipment size
| Gun head 230 * 98 * 58mm/control box 220 * 98 * 62mm [H * W * D] |
| Installation method | Floor/wall mounted |
| Install components | Wall mounted screw accessories |
| Wiring method | Up in and down out |
| Equipment weight | About 3.4KG |
| Cable specifications | 3*6mm²+0.75mm² |
| Cable length | 5 meters [supports customized line length] |
Electrical indicators | input voltage | AC240V |
| Input frequency | 50Hz/60Hz |
| maximum power | 7.4KW |
| output voltage | AC240V |
| Output current | 32A |
| standby power | 3W |
Environmental indicators | usage scenarios | Indoor/Outdoor |
| Working humidity | 5% -95% non condensing |
| working temperature | -30℃～+50℃ |
| Working altitude | <2000 meters |
| Protection level | Gun head IP67/control box IP67 |
| Cooling method | Natural cooling |
| Safety regulations and standards | SAEJ1772 |
| Flame retardant grade | UL94 V0 |
| Product Certification | UL,FCC |
Functional design | man-machine interface | LED indicator light |
| communication interface | / |
| Packaging specifications | Box gauge/weight | 505*505*298mm |
safety design
| Undervoltage protection, overvoltage protection, overload
protection, overcurrent protection, over temperature protection,
leakage protection, grounding protection, lightning protection,
electrostatic protection, flame retardant protectionretardant
protection |
Application
Suitable for American standard new energy vehicle home emergency
electricity, outdoor travel, emergency relief, outdoor work and
other occasions, charging anytime and anywhere.
It has an IP67 dustproof and waterproof rating, which can
effectively resist the erosion of rain, snow, and dust. This
ensures that you can use it with peace of mind even on stormy days.
