Portable 7.4KW Home EV Charging Station HD-AMB106
Product Description
1. Portable household portable charger
2. After charging and use, it can be carried with the vehicle
3. The power of the device is as low as 3W in the on-machine state,
saving energy and low consumption
4. Three color charging indicator light, indicating charging
related values
Describe
The HD-AMB106 charging gun is a portable charging product that
meets the American AC power standards, with a rated maximum AC
output power of 7.4KW and a weight of approximately 3.4KG. It is
suitable for household new energy on-board chargers, outdoor
travel, emergency relief, and outdoor work.
General specifications
| Detailed parameters | Parameter Details |
| Name and model | HD-AMB106 |
Appearance structure | plug model | NEMA 5-15P |
| product type | Plug and Charge |
| Shell material | Gun Head - Control Box PC9330 |
Equipment size
| Gun head 230 * 98 * 58mm/control box 220 * 98 * 48mm [H * W * D] |
| Installation method | Floor/wall mounted |
| Install components | Wall mounted screw accessories |
| Wiring method | Up in and down out |
| Equipment weight | About 3.4KG |
| Cable specifications | 3*6mm²+0.75mm² |
| Cable length | 5 meters [supports customized line length] |
Electrical indicators | input voltage | AC240V |
| Input frequency | 50Hz/60Hz |
| maximum power | 7.4KW |
| output voltage | AC240V |
| Output current | 32A |
| standby power | 3W |
Environmental indicators | usage scenarios | Indoor/Outdoor |
| Working humidity | 5% -95% non condensing |
| working temperature | -30℃～+50℃ |
| Working altitude | <2000 meters |
| Protection level | Gun head IP67/control box IP67 |
| Cooling method | Natural cooling |
| Safety regulations and standards | SAEJ1772 |
| Flame retardant grade | UL94 V0 |
| Product Certification | UL,FCC |
Functional design | man-machine interface | LED indicator light |
| communication interface | / |
| Packaging specifications | Box gauge/weight | 505*505*298mm |
safety design
| Undervoltage protection, overvoltage protection, overload
protection, overcurrent protection, over temperature protection,
leakage protection, grounding protection, lightning protection,
electrostatic protection, flame retardant protectionretardant
protection |
Application
Suitable for American standard new energy vehicle home emergency
electricity, outdoor travel, emergency relief, outdoor work and
other occasions, charging anytime and anywhere.
Ten fold protection and safety escort
Make every charge worry free and reassuring
Short circuit protection
Lightning protection
Leakage protection
Overvoltage protection
Overcurrent protection
Undervoltage protection
Overheat protection
Grounding protection
Emergency stop protection
Rainproof protection
